FEATURES
Traffic Management
Auto Negotiation of speed and duplex modes
802.3x Flow Control
DHCP Client
Dynamic MAC address management
IEEE 802.1Q-based or port-based VLAN
QoS based on WRR, strict priority, or both
Port-based and IEEE 802.1p-based QoS
QoS based on ToS (Type-of-Service)
DSCP Support (GS105E and GS105PE only)
Rate Limiting
Link Aggregation / Port Trunking (Static LAGs on 16 ports and 24 ports, Static LAGs and LACP on 48 ports)
Multicast Efficiency
IGMP snooping, v1, v2 and v3
Blocking of unknown multicast traffic
Act as static multicast router port
TECHNICAL SPECS
- Gigabit Ports : 5
- Warranty : Lifetime
- 10 Gbps Port : n/a
- Number of PoE ports : 2
- Total PoE Power budget (Watts) : PoE pass-thru: 19W with 802.3at / 7.9W with 802.3af input power
- Max MAC entries : 8K
- Buffer size : 2MB
- VLAN (Number Supported) : 64
- Number of LAGs & number of members : n/a
- Supported Mulitcast groups : 128
- Max number of source ports allowed (many to 1) : 4
- Internal/External : ***NO EXTERNAL POWER ADAPTER: This product requires PoE input power (802.3af or 802.3at) to operate; it has no means to power from AC.
- Max consumption (Watts) : 22W
- FAN : 0
- Acoustic Noise Level @25C (dBA) : 0
- Operating Temperature : 0° to 50° C
- MTBF : 1.685.972
- Electromagnetic Compliance (A or B) : B
PHYSICAL SPECIFICATION
- Weight (kg) : 3,46
- Dimensions (WxDxH) mm : 440x257x43
