FEATURES
Connectivity
Auto-negotiation for automatic connection at the highest common speed between switch and an end device.
Plug-n-Play
You can expand your network connections to multiple devices instantly.
Energy Saving
Energy-efficient technology for power and cost savings.
Speed
Non-blocking switching architecture for maximum throughput at wire speed.
Design
Fanless design for silent operation.
Cables
Auto-MDI/MDIX eliminates the need for crossover cables.
TECHNICAL SPECS
- Model Description : 5-Port Gigabit Ethernet Switch
- Speed : 10/100/1000Mbps Gigibit Ethernet
- Warranty : 3 Years
- Number of Ports : 5
- Connector Type : Plastic
- Switch Housing : Plastic
- LEDs : Power, Link/Activity
- Short Cable Power Saving : No
- Energy Efficient Ethernet Support (IEEE 802.3az) : Yes
- Jumbo Frame Support : 9,216 bytes
- MAC Table Size : 2K
- Packet Buffer Size : 1 Mbit
- DC Power Adapter : 5V / 0.7A
- Max Power Consumption (Watts) : 2.34W
- Acoustic Noise Level @ 25° C (dBA) : 0 dBA (Fanless)
- MTBF (@ 25° C) : 1,386,257 hours
- Electromagnetic compliance (A or B) : Class B
- Form Factor : Desktop or wall-mountable
PHYSICAL SPECIFICATION
- Dimensions (W x D x H) : 118 x 73 x 30 mm (4.6 x 2.9 x 1.2 in)
- Weight : 0.10 kg (0.22 lb)
